Rotary Screw Air Compressor Atlas Copco G 22 for Sale
Rotary Screw Air Compressor Atlas Copco G 22 for Sale Rotary Screw Air Compressor Atlas Copco G 22 for Sale Rotary Screw Air Compressor Atlas Copco G 22 for Sale
  • Rotary Screw Air Compressor Atlas Copco G 22 for Sale

Rotary Screw Air Compressor Atlas Copco G 22 for Sale

The Atlas Copco G 22 is a 30 HP (22 kW) oil-injected rotary screw air compressor designed for small and medium-sized businesses.
Request Quote PDF Format
Description Technical Parameter
Description
The robust, economical compressor
The all-new G 15L-22 belt-driven compressor from Atlas Copco is quiet, efficient, powerful, and reliable. In short, it checks all the boxes that matter most to small business owners. And what's even better, this robust quality comes with the lowest initial investment cost.

Features & benefits
Robust performance
100% continuous duty cycle.
Up to 46ºC/115ºF ambient temperatures.
Silent operation thanks to belt-driven element.
Full feature version with integrated refrigerant dryer and filters.
Simple installation & maintenance
Available in multiple configurations, including floor or tank-mounted.
Extremely small footprint with possible placement against a wall or in a corner.
The main components, the oil separator, and filter are easily accessible.
Easy monitoring & control
Icon-based display, pressure settings, temperature reading.
Running hours/hours working @ load.
Service warnings.
Outlet pressure setting directly on the controller.
Pressure and element outlet temperature reading.

Technical Parameter
Compressor Type Max. working pressure Capacity FAD* Installed motor
power		 Noise
level**		 Weight***
WorkPlace WorkPlace
Full Feature		 FM FM FF TM TM FF
bar(e) psig bar(e) psig l/s m3/hr cfm kw hp dB(A) kg kg kg kg
50 Hz Version
G 15L
7.5 7.5 108.8 7.3 105 42.5 153.0  90.1 15 20 67 313 371 537 595
10 10 145.0  9.8 141 38.5 138.6 81.6 15 20 67 313 371 537 595
13 13 188.5 12.8 185 31.2 112.3 66.1 15 20 67 313 371 537 595
G 18
7.5 7.5 108.8 7.3 105 52.1 187.6 110.4 18 25 69 328 392 545 609
10 10 145.0  9.8 141 45.4 163.4 96.8 18 25 69 328 392 545 609
13 13 188.5 12.8 185 38.5 138.6 81.6 18 25 69 328 392 545 609
G 22
7.5 7.5 108.8 7.3 105 62.0  223.2 131.4 22 30 70 344 408 561 625
10 10 145.0  9.8 141 54.1 194.7 114.5 22 30 70 344 408 561 625
13 13 188.5 12.8 185 46.4 167.1 98.3 22 30 70 344 408 561 625
60 Hz Version
G 15L
100 7.4 107 7.2 104 44.0  158.4 93.2 15 20 67 313 371 537 595
125 9.1 132 8.9 129 38.8 139.7 82.2 15 20 67 313 371 537 595
150 10.8 157 10.6 154 37.0  133.2 78.4 15 20 67 313 371 537 595
175 12.6 182 12.3 178 32.7 117.7 69.3 15 20 67 313 371 537 595
G 18
100 7.4 107 7.2 104 51.8 186.5 109.8 18 25 69 328 392 545 609
125 9.1 132 8.9 129 46.9 168.8 99.4 18 25 69 328 392 545 609
150 10.8 157 10.6 154 43.3 155.9 91.7 18 25 69 328 392 545 609
175 12.6 182 12.3 178 39.9 143.6 84.5 18 25 69 328 392 545 609
G 22
100 7.4 107 7.2 104 60.5 217.8 128.2 22 30 70 344 408 561 625
125 9.1 132 8.9 129 53.7 193.3 113.8 22 30 70 344 408 561 625
150 10.8 157 10.6 154 48.6 175.0  103.0  22 30 70 344 408 561 625
175 12.6 182 12.3 178 46.0  165.6 97.5 22 30 70 344 408 561 625


* Unit performance measured according to ISO 1217 ed. 4 2009, annex C, latest edition.
** Mean noise level measured at a distance of 1 m according to ISO 2151:2004 using ISO 9614/2 (sound intensity method); tolerance 3 dB(A). ** Mean noise level measured at a distance of 1 m according to ISO 2151:2004 using ISO 9614/2 (sound intensity method); tolerance 3 dB(A).
*** FM: Floor-mounted, FM FF: Floor-mounted Full Feature, TM: Tank-mounted, TM FF: Tank-mounted Full Feature.

Reference conditions:
Absolute inlet pressure 1 bar (14.5 psi).
Intake air temperature 20℃/68℉.
Maximum working pressure:
13 bar(e) (188 psig)
FAD is measured at the following effective working pressures:
7 bar(e), 9.5 bar(e), 12.5 bar(e)

Options
Integrated filter
Electronic Water Drains (EWD) on coolers
Air receiver drain EWD
Tropical thermostat
FoodGrade oil
Roto Synthetic Xtend oil
Wooden package
Performance certificates

Dimensions
FM Standard: 1130mm*833mm*1220mm
FM Full Feature: 1280mm*833mm*1220mm
TM: 1921mm*833mm*1832mm
